Secure high-pressure piping assemblies with rugged forged fittings, featuring micrometric sealing face flatness and precise bolt-hole alignment for field installation.
High-speed CNC vertical turning centers process forged carbon steel, maintaining precise raised-face flatness and ASME B16.5 compliance to prevent critical fluid or gas gasket leakage under extreme system pressure.
Automated multi-spindle drilling lines easily manage high-volume global industrial programs. We complement this mass-production capacity with comprehensive engineering services, providing complete material traceability reports and ultrasonic non-destructive testing.
Our production line manufactures high-pressure forged steel connection interfaces engineered to precise geometric industrial piping dimensions.
| Manufacturing Parameters | Technical Specifications |
|---|---|
| Material Grade | ASTM A105 / A350 LF2 / F316L Stainless Steel |
| CNC Turning Diameter | Up to 1200 mm maximum outer diameter flange capacity |
| Sealing Face Flatness | Maintained within 0.030 mm to eliminate fluid bypass |
| Bolt Hole Parallelism | Kept under 0.050 mm relative to center axis |
| Surface Roughness Profile | Controlled between 3.2 µm and 6.3 µm (Ra finish) |
| Pressure Rating Classes | Class 150 up to Class 2500 per ASME standards |
| Wall Thickness Tolerance | Complies strictly with ASTM manufacturing dimensional boundary limits |
Vertical turning centers hold sealing face flatness within thirty microns.
Closed-die forged steel eliminates internal material defects under pressure.
Automated drilling cells deliver thousands of flawless flanges monthly.
We integrate advanced machining, specialized materials, and surface finishing to deliver mission-critical parts that meet every rigorous automotive standard.
